Hooklift Multilift XR21S59 CHU
User Manual
M
M
!
!
6. Lowering the liftframe to the ground
6.1 - continue the movement until the lower corners of the liftframe touch the
ground
6.2 - stop the movement by releasing the control lever.
Monitor the lower ends of the liftframe during the movement.
If the body is in danger of colliding with the rear rollers, stop the
movement before colliding and drive the horizontal movement
upwards.
5. Drive the middle frame back
- drive the middle frame back by moving the control lever back
(main cylinders out).
- ”frame not down” signal light is lit, when the middle frame is lifted o the
subframe.
MAKE SURE THAT THE GROUND IS FIRM! A liftframe support
sinking may cause the frame to fall over.
If necessary, place e.g. a piece of plank under the support.
6. Supporting the liftframe
Support the liftframe using heavy wooden or metal supports!
