XR21S59 CHU 167
1/2018
113813003
Hooklift Multilift XR21S59 CHU
Service Manual
!
Hooklift supported to tipping position
If the work is done under the rear frame, the equipment must be lifted to tipping position
and the frames supported with separate tipping support in the correct places. Remember
to remove the support after the work has been completed.
BE AWARE!
Never move the middle frame or the rear frame by means
of hydraulics against the tipping support. The equipment
cylinders are powerful enough to break the support or the
frames and there is a great risk of personal injury. Stop the
movement of the main cylinders immediately when the frame
reaches the support.
Stop the truck engine always when doing service work under the raised frame and under
the container.
Use ladders and working platforms when required.
Do not utilise the hooklift components for climbing up the equipment.
