In the vicinity of the control units there must be no obstacles or loose objects that might
accidentally activate unit´s functions.
If the equipment has not been used for two weeks or longer, all safety functions must be
checked before the equipment is used again.
Avoid the unnecessary use of the main pressure relief valve. Heating up of the oil reduces
the quality of it and results in shorter life span of retaining rings and gaskets.
In subzero temperatures (< 0°C) it is recommended to let the pump idle for around 1 minute
in order for the hydraulic oil to be warmed up.
During the use of the equipment the engine noise will increase due to additional loading.
Noise level will also increase if the atrack/body is pulled along the ground during loading
or unloading of it.
When the equipment is used carefully and in a sensibly planned manner, the noise level
can be kept lower.
Take care that the truck or the hooklift is not overloaded. Observe the factory data for
the truck with regard to maximum permissible axle load/GVW. See also the axle load
calculations!
Strong winds will have an eect on the operation during loading, unloading or tipping of
the atrack/body.
The locking signal light is red and it is lit when the body and tipping locks are OPEN (changing
a atrack/body). The light blinks when the body and/or tipping locks are in a transitional
position, i.e. their movement is prevented.
If the light doesn’t go out when the locks are engaged, or if it isn’t lit when they are open,
investigate and x the cause immediately.
If the vehicle is left in a public place, the demountable should always be left in transport
position on top of the sub frame.
Check that the atrack/body is suitable for the load to be transported.
Ice can build up in the equipment in subzero temperatures 0
o
C. This may hinder or prevent
some movements.
