XR21S59 CHU 181
1/2018
113813003
Hooklift Multilift XR21S59 CHU
Service Manual
103
115
116
101
114
117
108
108
+
101
108
+
114
If a failure happens in the electric system of the device, the device may be restored to its
normal state, by operating the control valve manually:
1. Press down the button located at the end of valve for needed direction (101 or 114)
and hold it down.
2. Press down the button located at the end of free circulation valve (108).
3. Release the buttons when you would like to stop the movement.
Note!
The valve stem return spring (101 or 114) is
rather rigid and requires eort to push the
button to the bottom.
You can use the emergency movement
lever MU111568801 (additional equipment,
located behind the valve stand) as an
auxiliary tool.
