XR21S59 CHU 24
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
H
T
H
T
L
min. DIN 240 mm
min. DIN 280 mm
The condition of the atrack/body must be checked regularly. Especially if you are going to
use a type of atrack/body with which you are not familiar. In particular, check the condition
of the locking points and the condition and position of the lifting hook.
The maximum allowed wear of the lifting hook is 10 % from its nominal diameter. Nominal
diameter must be checked with the hooklift equipment supplier.
The longitudinal rails at the bottom of the atrack/body are under heady burden. Carry out
daily checks of these components for wear or damage.
If the atrack/body is frozen to the ground, do not pull it loose by using the XR hooklift
equipment. Use, for example, a forklift truck.
