Hooklift Multilift XR21S59 CHU
User Manual
CXXX / dXXX
>>>>>>>
M
M
A
Safety codes
8. Drive the horizontal movement into
rear position
- push the rearmost button in the
bottom row on the either side of
the control unit
- horizontal movement slides
backwards (cylinder in)
- mechanical tipping lock opens
when the hook frame is in rear
position.
8. Horizontal movement into rear
position
- keep the control lever in rear
position
- horizontal movement slides
backwards (cylinder in)
- mechanical tipping lock opens
when the hook frame is in rear
position.
9. Drive the middle frame back
- drive the middle frame back by
moving the control lever back (main
cylinders out).
- ”frame not down” signal light is lit,
when the middle frame is lifted o󰀨
the sub frame
- stop the movement by releasing
the control lever, when the hook is
slightly below the atrack/body
gripping bar.
9. Middle frame back
- keep the control lever in rear
position. Middle frame turns back
(main cylinders out).
- ”frame not down” signal light is lit,
  whenthemiddleframeisliftedo
the sub frame
- stop the movement by releasing
the control lever, when the hook is
  slightlybelowtheatrack/body
gripping bar.
10. Gripping the atrack/body gripping bar
(manual mode A5 and automatic mode A1)
- reverse the truck carefully, until the hook frame comes close to the atrack/
body gripping bar.
