Hooklift Multilift XR21S59 CHU
User Manual
CXXX / dXXX
>>>>>>
A
M
Safety codes
Select manual mode A5
- push the A5 button for approx. 2 s.
11. Lifting the atrack/body from the
ground
- move the control lever forward
(main cylinders in)
- signal lights “locks not closed”,
”URB in” and ”frame not down” on
the control unit are lit
- the main cylinder piston rods move
inwards.
Safety lock of the gripping hook gives
way to the gripping bar pushing into
the hook.
- release the control lever when the
hook starts to lift the atrack/body.
Make sure that the gripping bar is
properly inside the lifting hook and
the safety lock is engaged.
Choose automatic mode A1
- push the A1 button for approx. 2 s.
11. The atrack/body comes free from
the ground
- move the control lever slowly
forward
- signal lights “locks not closed”,
”URB in” and ”frame not down” on
the control unit are lit
- main cylinder piston rods move
inwards.
Safety lock of the gripping hook
gives way to the gripping bar
pushing into the hook.
- release the control lever when the
  hookstartstolifttheatrack/body.
Make sure that the gripping bar is
properly inside the lifting hook and
the safety lock is engaged.
