Hooklift Multilift XR21S59 CHU
User Manual
CXXX / dXXX
>>>>>
A
M
M
12. Middle frame forward
(beginning of the movement)
- move the control lever forward
- the main cylinder piston rods
move inwards.
12. Middle frame forward
(beginning of the movement)
- move the control lever forward
- the main cylinder piston rods
move inwards.
Safety codes
A short atrack/body may accidentally collide with the rear rollers during loading. The
darkened part of the atrack/body in the picture should not come in contact with the rear
rollers of the rear beam. The situation can be prevented by lifting the atrack/body with
horizontal movement.
Note! Horizontal movement during loading can only be done
in manual mode A5.
12A. Horizontal movement during loading (only in manual mode A5).
Select manual mode A5
- push the A5 button for approx. 2 s.
Drive the telescope cylinder out
- by pushing the front button in the bottom row on the either side of the control unit
- release the button when the front of the atrack/body has visibly risen above
the rear rollers.
Continue the movement of phase 12 in phase 13 after raising the atrack/body.
