Hooklift Multilift XR21S59 CHU
User Manual
CXXX / dXXX
>>>>
A
M
M
MANUAL MODE
Continue in manual mode A5.
13. Middle frame forward
- move the control lever forward
- the main cylinder piston rods move
inwards.
Make sure that the atrack/body is
lifted in line with the rear rollers.
Steering the truck will ensure
simultaneous contact between the
atrack/body and both rear rollers.
14. Activate the handbrake when the
rear end of the atrack/body is
lifted from the ground.
AUTOMATIC MODE
If you performed phase 12A,
please choose automatic mode A1
- push the A1 button for approx. 2 s.
13. Middle frame forward
- move the control lever forward
- the main cylinder piston rods move
inwards.
 Makesurethattheatrack/bodyis
lifted in line with the rear rollers.
Steering the truck will ensure
simultaneous contact between the
 atrack/bodyandbothrearrollers.
14. Activate the handbrake when the
rear end of the atrack/body is
lifted from the ground.
Safety codes
15. Middle frame forward
(end of the movement)
- keep the control lever in front
- main cylinder piston rods move
inwards
- “frame not down” signal light on the
control unit goes out, when the
middle frame comes down.
The speed of lowering the atrack/
body must be reduced by lowering the
engine speed in the last phase of the
main cylinder movement.
15. Middle frame forward
(end of the movement)
- keep the control lever in front
- main cylinder piston rods move
inwards.
- “frame not down” signal light on
the control unit goes out, when
the middle frame comes down.
 Thespeedofloweringtheatrack/
body must be reduced by lowering
the engine speed in the last phase of
the main cylinder movement.
