Hooklift Multilift XR21S59 CHU
User Manual
CXXX / dXXX
>>>
A
M
M
The main cylinders are released
(oating) when the atrack/body is
about 60 mm above the body
supports, and the nal stage of
unloading is dampened.
16. Horizontal movement forward
- by pushing the front button in the
bottom row on the either side of the
control unit (telescope cylinder out)
Release the button when the
atrack/body is in the right place
(short ones) or the horizontal
movement has reached the atrack/
body home position (approx. 350 mm
from the stow/unstow position of
horizontal movement).
Make sure the rear end of the
atrack/body never comes over
the rear rollers.
The main cylinders are released
 (oating)whentheatrack/bodyis
about 60 mm above the body
 supports,andthenalstageof
unloading is dampened.
16. Horizontal movement forward
- keep the control lever in the front
(telescope cylinder out).
Release the switch when the
 atrack/bodyisintherightplace
(short ones) or the system has
stopped the horizontal movement.
Make sure the rear end of the
atrack/body never comes over
the rear rollers.
17. Closing body locks
- close the body locks by pressing
the ”bodylocks close” button
- the signal light “locks not closed”
should go out.
17. Closing body locks
- body locks close when the control
lever is released
- the “locks not closed” signal light
on the control unit goes out
Safety codes
18. Shut o󰀨 the oil supply of the hydraulic pump.
19. Check that all signal lights of the control unit have gone out.
