8. Open the body locks
- push the ”bodylocks open” button
- under-run bar is retracted,
if it is not in
- URB signal light on the control
unit is lit, when the under-run bar
is fully in the in position
- when the locks are open, the “locks
not closed” signal light on the
control unit is lit.
8. Opening the body and tipping
locks
- move the control lever slowly
backwards
- under-run bar is retracted,
if it is not in
- URB signal light on the control
unit is lit, when the under-run bar
is fully in the in position
- body locks will open
- when the locks are open, the
“locks not closed” signal light on
the control unit is lit.
9. Drive the horizontal movement into
rear position
- push the rearmost button in the
bottom row on the either side of
the control unit
- horizontal movement slides
backwards (cylinder in)
- mechanical tipping lock opens
when the hook frame is in rear
position.
9. Horizontal movement into rear
position
- keep the control lever in rear
position
- horizontal movement slides
backwards (cylinder in)
- mechanical tipping lock opens
when the hook frame is in rear
position.
