13. Drive the truck forward. Engage the parking brake.
Continue in manual mode A5.
14. Middle frame forward (beginning
of the movement)
- move the control lever forward
(main cylinders in)
- signal lights “locks not closed”,
”URB in” and ”frame not down” on
the control unit are lit
- the main cylinder piston rods move
inwards.
Drive the middle frame down, all the
way onto the sub frame.
- “frame not down” signal light on the
control unit goes out, when the
middle frame comes down
The main cylinders are released
(oating) when the atrack/body is
about 60 mm above the body
supports, and the nal stage of
unloading is dampened.
Stop the movement when the middle
frame rests on the sub frame by
releasing the control lever.
Continue in automatic mode A1.
14. Middle frame forward (beginning
of the movement)
- move the control lever forward
- signal lights “locks not closed”,
”URB in” and ”frame not down”
on the control unit are lit
- the main cylinder piston rods move
inwards.
Drive the middle frame forward
by keeping the control lever in
middle position in the front.
- “frame not down” signal light on
the control unit goes out, when
the middle frame comes down
The main cylinders are released
 (oating)whentheatrack/bodyis
about 60 mm above the body
 supports,andthenalstageof
unloading is dampened.
