XR21S59 CHU 73
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
A
M
M
CXXX / dXXX
>
15. Horizontal movement forward
- keep the control lever in the front
(telescope cylinder in).
15. Horizontal movement forward
- by pushing the front button in the
bottom row on the either side of the
control unit (telescope cylinder in).
Release the button when the
horizontal movement has reached the
atrack/body home position (approx.
350 mm from the stow/unstow
position of horizontal movement).
16. Closing body locks
- close the body locks by pressing
the ”bodylocks close” button
- the signal light “locks not closed”
should go out.
16. Closing body locks
- body locks close when the control
lever is released
- the “locks not closed” signal light
on the control unit goes out.
Always drive in trac with the middle frame lowered
onto the sub frame.
17. Shut o the oil supply of the hydraulic pump.
18. Check that all signal lights of the control unit have gone out.
Safety codes
