8. Move the hook frame/middle frame with the atrack/body backwards
- drive the middle frame by moving the control lever back (main cylinders out)
- ”frame not down” signal light is lit as the middle frame is lifted from the sub frame
- continue the movement until the front of the atrack/body is almost down.
9. Keep the atrack/body front end up and slide it backwards
- use horizontal movement in turns by pushing the rearmost button in the bottom
row on the left side of the control unit
- or the middle frame by moving the control lever backwards.
Continue the movement until the atrack/body stands completely on the trailer or
on the platform.
10. Open the safety lock of the gripping hook, move the hook/middle frame a bit
more and release the hook from the atrack/body gripping bar
- open the safety lock of the gripping hook by pressing the button on the control
unit just before the front of the atrack/body is lowered to the ground
- continue the main cylinder movement with the safety lock open and downward
until the hook is released from the gripping bar
- stop the movement by releasing the control lever.
11. Move the sliding frame/middle frame to forward position
- keep the control lever in front position until the entire body rests on the sub frame
- “frame not down” signal light on the control unit goes out, when the middle frame
comes down.
12. Move the sliding frame forwards
- push the front button in the bottom row on the left side of the control unit.
Continue the movement until the frame is in the forward position.
The hooklift equipment is now in transport position.
13. Close the hydraulic body locks
- press the “body locks closed” button
- signal light “locks not closed” must go out.
14. Shut o󰀨 the oil supply of the hydraulic pump.
15. Check that all signal lights of the control unit have gone out.
