MULTILIFT XR S - Page 91

XR21S59 CHU 91
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
M
A
M
M
A
5B. Select manual mode A5 in case the horizontal movement has been driven
to the stow/unstow position, in front of the atrack/body home position.
- push the A5 button for approx. 2 s.
- push the rearmost button in the bottom row on the either side of the control unit
- horizontal movement slides backwards (cylinder in)
- stop the horizontal movement after it has moved at least 350 mm backwards
6. Open the body locks
- push the ”bodylocks open” button
- “locks not closed” signal light on the
control unit is lit, when the locks are
fully open.
6. Opening body locks
- move the control lever slowly
backwards
- the body locks open
- “locks not closed” signal light on
the control unit is lit, when the
locks are fully open.
7. Drive the horizontal movement into
rear position
- push the rearmost button in the
bottom row on the either side of
the control unit
- horizontal movement slides
backwards (cylinder in)
- mechanical tipping lock opens
when the hook frame is in rear
position.
7. Horizontal movement into rear
position
- keep the control lever in rear
position
- horizontal movement slides
backwards (cylinder in)
- mechanical tipping lock opens
when the hook frame is in rear
position.
