Hooklift Multilift XR21S59 CHU
User Manual
M
A
!
8. Drive the middle frame back
- drive the middle frame back by
moving the control lever back (main
cylinders out).
- ”frame not down” signal light is lit,
when the middle frame is lifted o󰀨
the sub frame
- stop the movement by releasing
the control lever, when the hook is
slightly below the liftfrme gripping
bar.
8. Middle frame back
- keep the control lever in rear
position. Middle frame turns back
(main cylinders out).
- ”frame not down” signal light is lit,
  whenthemiddleframeisliftedo
the sub frame
- stop the movement by releasing
the control lever, when the hook is
slightly below the liftfrme gripping
bar.
9. Gripping the liftframe gripping bar
(manual mode A5 and automatic mode A1)
- reverse the truck carefully, until the hook frame comes close to the liftframe
gripping bar.
DO NOT TIP OVER THE LIFTFRAME!
Ask another person to monitor the grabbing of the liftframe and
receive the liftframe support when it is released.
