12. Middle frame forward
(end of the movement)
- keep the control lever in front
- main cylinder piston rods move
inwards
- “frame not down” signal light on the
control unit goes out, when the
middle frame comes down.
The speed of lowering the middle
frame must be reduced by lowering
the engine speed in the last phase of
the main cylinder movement.
The main cylinders are released
(oating) when the middle frame is
about 60 mm above the body
supports, and the nal stage of
unloading is dampened.
12. Middle frame forward
(end of the movement)
- keep the control lever in front
- main cylinder piston rods move
inwards.
- “frame not down” signal light on
the control unit goes out, when
the middle frame comes down.
The speed of lowering the middle
frame must be reduced by lowering
the engine speed in the last phase
of the main cylinder movement.
The main cylinders are released
 (oating)whenthemiddleframeis
about 60 mm above the body
 supports,andthenalstageof
unloading is dampened.
13. Horizontal movement forward
- by pushing the front button in the
bottom row on the either side of the
control unit (telescope cylinder out)
Release the button when the
horizontal movement has reached the
atrack/body home position (approx.
350 mm from the stow/unstow
position of horizontal movement).
13. Horizontal movement forward
- keep the control lever in the front
(telescope cylinder out).
Release the switch when the
system has stopped the horizontal
movement.
