System description
User manual 57106_hdb_en_13 16 / 94
Power modules
Power modules provide the Cube20S
system with power. The power modules
are either integrated into the bus node or
may be plugged in between the expan-
sion modules.
Depending on the type of power module,
groups of potential can be defined for the
24 V DC power supply, or the electronics
supply may be extended by 2 A.
For better recognition, the power modules
have a color different from the expansion
modules.
