Configuration/settings
User manual 55170_hdb_en_13 70 / 145
Input delay
 defines the delay for evaluation of the digital inputs. That means the time
after which a signal change is detected.
 Default value for input delay: 1 ms
±0.5
Fig. 8-15: Input delay
E1 Voltage at input
E2 Logical value
t1 Input delay
