Navistar MaxxForce 7

SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES
ServiceProcedures(cont.)
PRIMARYFUELFILTER(cont.)
WARNING:Topreventpersonalinjuryordeath,donot
letengineuidsstayonyourskin.Cleanskinandnails
usinghandcleanerandwashwithsoapandwater.Washor
discardclothingandragscontaminatedwithengineuids.
WARNING:Topreventpersonalinjuryordeath,store
dieselfuelproperlyinanapprovedcontainerdesignedfor
andclearlymarkedDIESELFUEL.
WARNING:Topreventpersonalinjuryordeath,do
notmixgasoline,gasohol,oralcoholwithdieselfuel.A
heatsource,spark,orelectronicdevicecanignitethese
fuelmixtures.Thiscreatesarehazardandpossible
explosion.
WARNING:Topreventpersonalinjuryordeath,donot
smokeandkeepfuelawayfromamesandsparks.
Figure35PrimaryFuelFilterAssembly
1.ExhaustGasRecirculation(EGR)cooler
2.Primaryfuelltercap
3.PrimaryfuelltercapO-ring
4.Secondaryfuellter
5.Fuelcooler
6.Waterdrainvalve
7.PrimaryfuelelementO-ring
8.Primaryfuellterelement
Page81
