NEC NC1600C - Installation Configuration

“Confidential, Do Not Duplicate without written authorization from NEC.”
5-5
SERVICE MODE
Installation
Image Orient
The projection mode is selected for the projector.
LCD display Method of projection Method of installation
Normal–F Normal Front Normal Front projection
Normal–R Normal Rear Normal Rear projection
Example of display
Installation
Image Orient
(*)
<UpsideDown -R >
First line : Indication of "Installation"
Second line : Indication of "Image Orient"
Third line : Indication of current setup
Fourth line : Normal Front : “Normal –F”
UpsideDown Rear : “UpsideDown–R” (*1)
Normal Rear : “Normal–R”
UpsideDown Front : “UpsideDown–F” (*1)
(*1) Enabled only for the NC800C
Lens Calibrate
When the "Execute" ENTER key is pressed, positioning of the ZOOM and FOCUS lenses is carried out.
Example of display
Installation
Lens Center
< Execute >
First line : Indication of "Installation"
Second line : Indication of "Lens Center"
Third line : Void
Fourth line : Indication of "Execute"
Lens Center
When the ENTER key is pressed in "Execute" mode, the lens mount (lens shift) position is moved to the center
(reference position).
This is valid only in the directions of up, down, right, and left.
Example of display
First line : Indication of "Installation"
Second line : Indication of "Lens Center"
Third line : Void
Fourth line : Indication of "Execute"
Installation
Lens Calibrate
< Execute >
