NEC NC1600C - Page 334

9-94
“Confidential, Do Not Duplicate without written authorization from NEC.”
ASSEMBLY DIAGRAM
SERVICE
Diagram symbol Circuit symbol Part name Part code Q’ty Remarks
BAG,POLYTHLENE (270X370 25815061 1
ALKALINE BATTERY LR6(JE) 68151006 2
PRT1 WARRANTY ENVELOPE(100*220 78047921 4
PRT2 CELLO TAPE 24W*35M 92203030 0.01
PRT3 TAPE,SCOTCH NO.214 92203051 0
PRT4 BAND(TY-29M) 24C08551 4
PRT5 ATTACHMENT(4-7) 24H58481 1
SMALL IRIS(NC1600C) 24H61201 1
INSULATION SHEET(700*700) 24J29031 1
LABEL(WEEE)(HR) 24L57641 1
LABEL(10*30) 24L60411 2
CAUTION LABEL(KEY) 24L64461 1
PARTS BOX 24M21871 1
BATTERY ALKALINE(GP15A)AA 6N800008 2
CABLE REMOTE CONTROL 16M 7N520057 1
PROJECTOR WARRANTY(SHEET) 7N8P7491 1
NC1600C IMPORTANT INFO 7N8P7972 1
REM-T HAND UNIT RD-371E 7N900124 1
NC1600C MANUAL CD-ROM 7N951092 1
For more details, refer to the section of packaging method.
