ASSEMBLY DIAGRAM
Diagram symbol Circuit symbol Part name Part code Q’ty Remarks
PRT1 STOPPER 24282431 2
PRT2 TAPE,SCOTCH NO.214 92203051 0.01
PRT3 BAND,P.PROPYLEN 15.5MM 92203857 0.01
PRT4 LABEL(HDPE) 24L63251 4
PRT5 LABEL(CARTON)T 24L63921 1
LABEL(CARTON)L 24L63932 1
LABEL(CARTON)R 24L63942 1
SHEET,PROTECTION(L=3500) 24M21161 2
CARTON BOX ASSY 24MV1781 1
A 82N94951 1
PACKING
For more details, refer to the packing specification [01544041-H].
