NEC NC1600C - TAMPER-** PWB (PWC-4692**)

CONNECTION DIAGRAMS
“Confidential, Do Not Duplicate without written authorization from NEC.”
POT* Connect to PJDIV PWB (* = 1 to 8)
1 Tamper OK : Short to GND Tamper NG : Open
2 GND
3 Tamper OK : Open Tamper NG : Short to NG
12-22
TAMPER-** PWB (PWC-4692**) (** = from BA to BH)
