CONNECTION DIAGRAMS
“Confidential, Do Not Duplicate without written authorization from NEC.”
PON10 Connect to MOTHER PWB
1 Power good (L : Power OK H : Power NG)
2 GND
3 12V Main for TI board
4 GND
5 5V Main for TI board
6 GND
7 3.3V Main for TI board
8 GND
9 3.3V Main for TI board
10 GND
12-23
MOTHER PWB (PWC-4593M3)
PON11 Connect to MOTHER PWB
1 Power good (L : Power OK H : Power NG)
2 GND
3 12V Main for TI board
4 GND
5 5V Main for TI board
6 GND
7 3.3V Main for TI board
8 GND
9 3.3V Main for TI board
10 GND
PO6022 Connect to Tamper SW
1 OEM_KEY_ER_N
2 OEM_KEY_ER_P
PO6008 Connect to CPU PWB
1 OEM_PH_RESETZ (L : Rest H : Normal)
2 OEM_RS232_DTR
3 OEM_RS232_CTS
4 OEM_RS232_TD
5 OEM_RS232_RTS
6 OEM_RS232_RD
7 OEM_RS232_DSR
8NC
9 OEM_RS232_GND
PO6117 Connect to PJDIV PWB
1 Feedback line of 3.3V voltage
2 GND
3 Feedback line of 5V voltage
4 GND
5NC
PO6013 Connect to PJDIV PWB
1 OEM_KEY_ER_N
2 OEM_KEY_ER_P
To Next Page
