BSY32 Red B channel status
ON : B2 channel of the No. 3 circuit is in use.
OFF : B2 channel of the No. 3 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 3 circuit.
ZT is in make-busy status.
BSY31 Red B channel status
ON : B1 channel of the No. 3 circuit is in use.
OFF : B1 channel of the No. 3 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 3 circuit.
ZT is in make-busy status.
BSY30 Red B channel status
ON : B0 channel of the No. 3 circuit is in use.
OFF : B0 channel of the No. 3 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 3 circuit.
ZT is in make-busy status.
BSY22 Red B channel status
ON : B2 channel of the No. 2 circuit is in use.
OFF : B2 channel of the No. 2 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 2 circuit.
ZT is in make-busy status.
BSY21 Red B channel status
ON : B1 channel of the No. 2 circuit is in use.
OFF : B1 channel of the No. 2 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 2 circuit.
ZT is in make-busy status.
BSY20 Red B channel status
ON : B0 channel of the No. 2 circuit is in use.
OFF : B0 channel of the No. 2 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 2 circuit.
ZT is in make-busy status.
Continued on next page
LAMP
NAME
COLOR FUNCTION
PN-4CSIA-A (CSI)
