– 519 – NWA-008841-001 Rev.5.0
90ch3004.fm
Switch Settings
This card has no switches.
BSY12 Red B channel status
ON : B2 channel of the No. 1 circuit is in use.
OFF : B2 channel of the No. 1 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 1 circuit.
ZT is in make-busy status.
BSY11 Red B channel status
ON : B1 channel of the No. 1 circuit is in use.
OFF : B1 channel of the No. 1 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 1 circuit.
ZT is in make-busy status.
BSY10 Red B channel status
ON : B0 channel of the No. 1 circuit is in use.
OFF : B0 channel of the No. 1 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 1 circuit.
ZT is in make-busy status.
BSY02 Red B channel status
ON : B2 channel of the No. 0 circuit is in use.
OFF : B2 channel of the No. 0 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 0 circuit.
ZT is in make-busy status.
BSY01 Red B channel status
ON : B1 channel of the No. 0 circuit is in use.
OFF : B1 channel of the No. 0 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 0 circuit.
ZT is in make-busy status.
BSY00 Red B channel status
ON : B0 channel of the No. 0 circuit is in use.
OFF : B0 channel of the No. 0 circuit is in idle.
Flash (60 IPM) : ZT is not connected to the No. 0 circuit.
ZT is in make-busy status.
LAMP
NAME
COLOR FUNCTION
PN-4CSIA-A (CSI)
To Next Page
