Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 7
6
For Model B computers:
7. Pull the tab to slide the hard disk and case assembly in the direction of arrow .
8. Lift the hard disk and case assembly out of the bay in the direction of arrow .
9. Remove screws - to release the hard disk from the case , and
reverse the process to install any new hard disk.
7
8
9 10 11 12
Figure 6 - 6
HDD & Case
Assembly
Removal
(Model B
Computers Only)
7
Model B
10
11
12
8
9
To Next Page
