48
PROGRAMMING
NESS D8 (V4.7) CONTROL PANEL – INSTALLER MANUAL
1E 2E 3E 4E 5E 6E 7E 8E
ON = Factory default setting.
Enable Test Calls
Mains Report delay
Listen-in to dialler
Swinger shutdown
Line Fault Monitor
Line Fault to AUX2
Internal Timing
.
OPTION No DESCRIPTION
P89E Miscellaneous Reporting options
ON ON ON
ENABLE TEST CALLS
This option enables the reporting of dialler test calls to the Central station.
PROGRAMMING SE QUENCE:
P89E 1E toggles the option ON and OFF
P89E 1E OFF: No Test Calls
P89E 1E ON: Test Calls enabled
P89E 1E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
ON: Test Calls enabled
NOTES:
• RELATED OPTIONS:
P83E Test Call Interval
P84E Time before next Test call
P87E 4E Number Of Dialling Attempts
MAINS REPORT DELAY
This option allows Mains Fail reports to be delayed by one hour if the mains power
has been off continuously for that time. Normally, the Mains Fail report is sent
immediately the power fails.
PROGRAMMING SE QUENCE:
P89E 2E toggles the option ON and OFF
P89E 2E OFF: Mains Fail reports immediately
P89E 2E ON: Mains Fail report is delayed by 1 hour
P89E 2E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
ON: Mains Fail report is delayed
NOTES:
LISTEN-IN TO DIALLER
This is a diagnostic feature for installers. Listen-In is turned on for a minimum of 4
minutes after exiting Program Mode.
During Listen-In, the dialler message and other telephone tones can be heard
through the Siren output (at low volume) while the dialler is sending reports. The 4
minute period is restarted whenever any key on the keypad is pressed.
To turn Listen-In off, go back into Installer Program mode and toggle the option
OFF.
PROGRAMMING SE QUENCE:
P89E 3E toggles the option ON and OFF
P89E 3E OFF: No Listen-In
P89E 3E ON: Listen-In enabled
P89E 3E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
OFF: No Listen–In
NOTES:
• For convenient and private Listen-In,
temporarily connect a spare horn speaker
to the Siren output.
