19
PROGRAMMING
NESS D8 (V4.7) CONTROL PANEL – INSTALLER MANUAL
TEMPORARY DAY ZONES
D8 Version (v4.6 onwards) introduces the
‘Temporary Day Zone’ feature which allows
easy and fl ex i ble Day Zone selection and
op er a tion.
While remaining in normal operating mode,
the user can add and remove ‘Temporary
Day Zones’ and enable/disable day zone
operation using simple key strokes.
TO ENABLE TEMPORARY DAY ZONES
To en a ble Tem po rary Day Zone selection
and operation, the Brief Day Alarm feature
(installer op tion P64E 2E) must be ON. If
P64E 2E is OFF, the Temporary Day Zone
feature will be un a vail a ble but Permanent
Day Zones will still op er ate and will sound
the programmed output while the zone is
unsealed.
P64E 2E is OFF by default.
USER COMMANDS (In normal Op er at ing
Mode).
+ Selection Mode. Enter P
fol lowed by E when in op er at ing mode
to enter Tem po rary Day Zone se lec tion
mode.
[Zone No.]+
Zone Selection. To select
or deselect zones to be Tem po rary Day
Zones. The selected zones are in di cat ed
by the cor re spond ing zone number.
Permanent Day Zones, (set by installer
op tion P53E), are not displayed in selection
mode. Per ma nent Day Zones can be
selected as Tem po rary Day Zones but this
has no effect as those zones are already
day zones.
Saves changes and returns to nor mal
op er at ing mode.
+ Enables and Disables
Day Mode. This en a bles/dis a bles both
Tem po rary and Per ma nent Day Zones.
When Day Mode is enabled, any unsealed
day zone will sound the programmed
output for 2 seconds. When Day Mode is
disabled, an un sealed day zone will simply
be indicated on the keypad as an unsealed
zone. (Note: The key pad does not in di cate if
Day Mode is en a bled or dis a bled).
AUX 2 OPTION
When the Temporary Day Zone feature
is en a bled, the installer option P63E 6E
selects Aux 2 out put in stead of the strobe
output. This allows a remote warn ing de vice
such as a buzz er to be con nect ed for day
zone warn ing. This may be needed if an
additional audible day zone warn ing is
needed, although the keypad sonalert,
(P63E 7E), is more than adequate in most
cases.
RELATED OPTIONS
P64E 2E, Brief Day Alarm. Turn this option
on to enable Temporary Day Zones. Factory
default = OFF.
P63E 5E, Day Mode to Reset output.
P63E 6E, Day Mode to Strobe output.
If P64E 2E is ON, then this option sends day
alarms to the AUX 2 output.
P63E 7E, Day Mode to Sonalert.
P63E 8E, Day Mode to Siren output.
P53E, Permanent Day Zone selection.
Temporary Day Zone selections will be
lost if the pan el is powered down or reset,
but are not affected by arm ing/dis arm ing or
entering pro gram mode.
DAY ZONES
Day Zones operate when the panel is fully disarmed, i.e. when Area 1, Area 2 and
Monitor are all off. When alarmed, these zones will activate the as signed outputs
instantly.
The outputs mapped to the Day Zone will turn on while the zone is unsealed. Turn
P64E 2E on, to limit Day Zone alarms to 2 seconds.
PROGRAMMING SEQUENCE:
P53E [Zone No]E toggles the options ON and OFF
P53E [Zone No]E OFF: The zone is not a Day zone
P53E [Zone No]E ON: The zone is a Day zone
P53E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
all OFF: No Day zones
NOTES:
• RELATED OPTIONS:
P63E 5E-8E Day zone output mapping
P64E 2E Brief Day Mode alarm
• TYPICAL USES: Instant alert when a
delivery door is opened, doorway alert
for a shop.
24hr ZONES
24hr Zones operate at all times regardless of the mode of panel operation, i.e.
Armed, Disarmed or Monitor. When alarmed, these zones will activate assigned
outputs immediately. To reset those alarms a valid user code must be entered.
Selecting a zone as 24hr will override any other zone type setting such as Instant,
Delayed or Handover. 24hr zones are independent of Area operation. All other
zone types must be assigned to at least one Area to become active.
PROGRAMMING SEQUENCE:
P52E [Zone No]E toggles the options ON and OFF
P52E [Zone No]E OFF: The zone is not a 24hr zone
P52E [Zone No]E ON: The zone is a 24hr zone
P52E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
all OFF: No 24hr zones
NOTES:
• The Tamper input is always a 24hr zone
• For silent 24hr zones, deselect the zone/s from
options P54E-P57E (Reset, Strobe, Sonalert
& Siren)
• To change a 24hr zone to any other zone type,
the zone must also be re-assigned to an AREA
(P45E or P46E).
