Ness D8 Installation & Programming Manual

6
NESS D8 (V4.7) CONTROL PANEL – INSTALLER MANUAL
J1
J2
RECEIVER
PROG
TAMP
BATTERY
NESS SECURITY PRODUCTS
105-220
TELEPHONE
HEATSINK
J3
AUX1
AUX2
ARM1
ARM2
12V
0V
TAMP
+12V
+12V
+12V
0V
Z8
C
Z7
Z6
C
Z5
Z4
C
Z2
Z3
C
Z1
0V
CLK
DAT
COM
KEYPAD
RESET
STR
SIREN
17V
AC
AC
EARTH
12V DC Power
for detectors, etc
12V DC Power
for detectors, etc
Up to 2 x Ness 12V Siren (100-172)
OR 3 x Top Hat Screamer (100-238)
Up to 2 x Strobe Light (NOI-300)
Up to 3 x Horn Speaker, 8 Ohm (NOI-110)
Ness 17V AC Plug Pack (840-029)
(Australia only)
17V AC (Red & Black)
EARTH (White)
+12V
CLK
DAT
NESS LCD Keypad
(100-667)
NESS LED Keypad
(100-192)
COM
NORMALLY OPEN
( DEVICESN.O.)
NORMALLY CLOSED
( DEVICESN.C.)
Zone
C
2K2
2K2
Zone
C
Zone 2
Zone 6
Zone 4
Zone 8
Zone 1
Zone 5
Zone 3
Zone 7
Maximum
3 keypads
ZONE CONNECTION
2K2
2K2
2K2
2K2
2K2
2K2
2K2
2K2
BOX TAMPER LEADS
(supplied)
BOX TAMPER SWITCH
N.C. Contacts (WHITE)
(supplied)
J2 CONNECTOR
(Optional)
NESS RADIO INTERFACE
J3 HEADER
Provides Open Collector
outputs as marked.
J1 LINK
&BOX TAMPER PROGRAM LINK
= Sealed, normal state
= Tamper alarm state
Power up with link off to enter
installer program mode
BATTERY LEADS
(supplied)
BATTERY CONNECTION
Connect 12V 7Ah
backup battery
“HEARTBEAT” LED
Constantly flashes
2K2
N.O TAMPER SWITCH
(761-002) Colour: BLACK
Supplied with Ness siren covers
N.C TAMPER SWITCH (SWI920) Colour: WHITE
ALTERNATIVE TAMPER SWITCH WIRING
For N.C. Tamper Switches
2K2
TELEPHONE LEAD (Supplied)
Connect to Mode3 socket
The Tamper Switch
is readily identified being black in colour.
This tamper switch is now being to supplied
as standard with all Ness siren covers.
The Normally Open contacts are less prone
to flase activation in harsh climates.
NORMALLY OPEN The standard white
Tamper Switch is supplied with all Ness
control panels for box tamper.
NORMALLY CLOSED
NORMALLY OPEN
Tamper Switch
Part No: 761-002
Colour: Black
NORMALLY CLOSED
Tamper Switch
Part No: SWI920
Colour: White
TAMPER SWITCH IDENTIFICATION
D8 MAIN BOARD
NESS D8 CONNECTION DIAGRAM
© 2003 Ness Security Products
