Ness D8 Installation & Programming Manual

7
NESS D8 (V4.7) CONTROL PANEL – INSTALLER MANUAL
NESS D8
CONTROL
PANEL
TAMP
C
EXAMPLE 5
SIREN WIRING
EXTERNAL INTERNAL
TAMP
C
STR
RESET
SIREN
Alernative 12V Sirens:
100-172 Ness 12V Internal Siren
NOI230 S110 12V Piezo Screamer
NOI240 S100 12V Piezo Screamer
100-238 Top Hat 12V Piezo Screamer
NOTE:
Ness Panel & Noise KITS are
supplied with the Ness Internal
Horn Speaker (100-171). This must
be connected to the SIREN output
in parallel with the Horn Speaker/s.
RED
RED
BLACK
BLACK
N.O TAMPER SWITCH
(761-002) Colour: BLACK
N.C TAMPER SWITCH
(SWI920) Colour: WHITE
ALTERNATIVE TAMPER SWITCH WIRING
For N.C. Tamper Switches
STROBE LIGHT
(NOI300)
The terminal block should
be mounted inside the
siren cover.
HORN
SPEAKER
(NOI110)
NESS D8
CONTROL
PANEL
NESS D8
CONTROL
PANEL
NESS D8
CONTROL
PANEL
0V
ALARM
TAMPER
N.C.
N.C.
+12V
N.C.
N.C.
NESS QUANTUM DETECTOR
(all models)
REED SWITCH
(N.C. contacts))
PANIC BUTTON
(N.O. contacts))
Zone [1~8]
Zone [1~8]
Zone [1~8]
Zone [1~8]
0V
C
+12V
0V
CC
+12V
0V
CC
+12V
2K2
2K2
NESS QUANTUM DETECTORS
4 WIRE CONNECTION
NESS D8
CONTROL
PANEL
0V
ALARM
TAMPER
N.C.
N.C.
+12V
N.C.
N.C.
NESS QUANTUM DETECTOR
(all models)
TAMP
0V
CC
C
+12V
2K2
2K2
EXAMPLE 2
NESS QUANTUM DETECTORS
6 WIRE CONNECTION
With Tamper
EXAMPLE 4
ANY N.C. DEVICE
ANY N.O. DEVICE
NC
NO
COM
EXAMPLE 1 EXAMPLE 3
2K2
2K2
2K2
SIREN IDENTIFICATION:
WHITE
BLACK -
WHITE
RED +
100-171
Ness Internal Horn Speaker.
(WHITE wires).
Connects to SIREN output.
100-172
Ness 12V Internal Siren.
(RED & BLACK wires).
Connects to RESET output.
NESS D8 CONNECTION EXAMPLES
