Ness ECO8x Installation & Programming Manual

QUICK START PROGRAMMING
Use one of these programming summaries for fast setup of your Ness ECO8x control
panel as a Local, Audible Monitored or Central Station Monitored system.
QUICK START 1 - LOCAL
SYSTEM
Quick Start 1 shows you how to
change User Code 1 (the Master
Code).
* Default Master Code is: 123
* Default Installer Code is: 000000
QUICK START 1
STEP KEYSTROKES DESCRIPTION COMMENT
1 P 1 2 3 E* Enters User Program Mode. Program light will turn on.
2
P 1 1 E
Selects the option for User Code 1. The existing code will be displayed
on the keypad one digit at a time.
3 _ _ _ _ E Enter your new PIN code followed
by E.
Keypad codes can be 3 to 6 digits
in length.
4 _ _ _ _ E Enter your new PIN code again. The new code will be displayed on
the keypad one digit at a time.
5 P E To exit program mode. Program light will turn off.
QUICK START 2
STEP KEYSTROKES DESCRIPTION COMMENT
1 P 1 2 3 E* Enters User Program Mode. Program light will turn on.
2 P 0 0 0 0 0 0 E* Enters Installer Program Mode. Program light will flash.
3
P 1 1 E
Selects the option for User Code 1. The existing code will be displayed
on the keypad one digit at a time.
4 _ _ _ _ E Enter your new PIN code followed
by E.
Keypad codes can be 3 to 6 digits
in length.
5 _ _ _ _ E Enter your new PIN code again. The new code will be displayed on
the keypad one digit at a time.
6 P 8 6 E 4 E Turns on option P86E 4E Enables Audible Monitoring.
7 P 7 0 E Selects the option for Telephone
Number 1.
The existing number will be displayed on
the keypad one digit at a time.
8 _ _ _ _ _ _ _ _ E
Enter the telephone number
followed by E. (max. 30 digits)
The new number will be displayed on the
keypad one digit at a time.
9 P E To exit program mode. Program light will turn off.
QUICK START 2 -
AUDIBLE MONITORING
Quick Start 2 shows you how to
change User Code 1 (the Master
Code), enable Audible Monitoring
and program a telephone number.
This will enable the dialler to report
alarms to any telephone including
mobile phones.
QUICK START 3 -
CENTRAL STATION
MONITORING
Quick Start 3 shows you how to
change User Code 1 (the Master
Code), enable Central Station
Monitoring and program one
telephone number. This will enable
the dialler to report alarms to a
Central Station.
QUICK START 3
STEP KEYSTROKES DESCRIPTION COMMENT
1 P 1 2 3 E* Enters User Program Mode. Program light will turn on.
2 P 0 0 0 0 0 0 E* Enters Installer Program Mode. Program light will flash.
3
P 1 1 E
Selects the option for User Code 1. The existing code will be displayed
on the keypad one digit at a time.
4 _ _ _ _ E Enter your new PIN code followed
by E.
Keypad codes can be 3 to 6 digits
in length.
5 _ _ _ _ E Enter your new PIN code again. The new code will be displayed on
the keypad one digit at a time.
6 P 8 6 E 2 E Turns on option P86E 2E Enables Contact ID format.
7 P 7 0 E Selects the option for Telephone
Number 1.
The existing number will be displayed on
the keypad one digit at a time.
8 _ _ _ _ _ _ _ _ E
Enter the telephone number
followed by E. (max. 30 digits)
The new number will be displayed on the
keypad one digit at a time.
8 P 7 2 E
Selects the option for the Client
Account Number.
The existing number will be displayed on
the keypad one digit at a time.
10 _ _ _ _ E
Enter the Account number
followed by E. (4 digit account number
supplied by your monitroing company.)
The new number will be displayed on the
keypad one digit at a time.
11 P E To exit program mode. Program light will turn off.
10
Ness eCO8x CONtrOl PaNel – INstallatION MaNual
P R O G R A M M I N G

Ness ECO8x Specifications

Power

plug pack voltage	240 V AC
plug pack output voltage	17 V AC
plug pack output current	1.4 A
power supply voltage	13.8 V DC
power supply current	800 mA

Battery

battery voltage	12 V
battery capacity	7.0 Ah
battery charging current	350 mA

Inputs and Outputs

zone inputs	8
end of line resistor	2200 Ohms
maximum keypads	3

Weight and Dimensions

box width	235 mm
box height	300 mm
box depth	90 mm
