NESS ECO8x CONTROL PANEL
SPECIFICATIONS
Box dimensions .....................235w x 300h x 90d mm.
Plug pack ............................... 240V AC, output 17V AC@1.4A.
Power supply ......................... 13.8V DC @ 800mA.
Quiescent current draw .........80mA with 1 keypad.
Operating voltage .................. 9.5V– 14V DC.
Rechargeable battery............. 12 volt 7.0 Amp/hour Sealed Lead Acid.
Battery charging current ........
350mA maximum, current limited.
Dynamic battery test .............. Backup battery is tested under load, hourly and on arming.
Fuses ...................................... 2 Amp auto resetting / Siren output & Reset output.
500mA auto resetting / 12 volt auxiliary outputs.
200 mA auto resetting / strobe output.
INPUTS
Zones ..................................... 8 zone inputs. 1 x 24hr tamper input.
End of line resistor ................. 2200 Ohms (2K2).
Maximum keypads .................
3.
RADIO Header .......................Multi-pin connector for the Ness Radio Interface (100-200).
OUTPUTS
Siren .......................................
On board siren driver with timed output .
Maximum 3 x 8 Ohm horn speakers.
Strobe ..................................... 12V DC timed output. Maximum 2 x 1 Watt strobe lights.
Reset ...................................... 12V DC timed output. Maximum 2 x 12V piezo screamers.
Equipment power output ....... 13.8V DC output for powering detectors and other equipment. Maximum
500mA.
AUX1 Output .......................... Programmable AUX1 output. Switches negative, max. draw 200mA.
AUX Header ...........................Programmable AUX2 output. Switches negative, max. draw 100mA.
APPROVALS
EMC COMPLIANCE
EN 50130-4:1996 Part 4: Electromagnetic compatability. Electrostatic Discharge, Radiated RF Immunity,
Electrical Fast Transient/burst. Surge Immunity, Conducted RF Immunity, Voltage Dips and Interruptions,
Mains Supply Variations.
AS/NZ CISPR 22:2002- Class B, Electromagnetic Radiation, Terminal Disturbance Voltage.
EN61000-6-3:2001, Harmonic Current Emissions, Voltage fluctuations and Flicker.
TELECOM
TBR21, EU. PTC200, NEW ZEALAND TELECOM . AS ACIF S002, AUSTRALIA
SAFETY
EN60950:2000 inc Country Deviations, Safety of Information Technology Equipment
AS/NZ3260-1993 incl. AMDTS 1,2,3 &4. TS001-1997 ACA Australian Communications Authority
PACKING LIST
1 ECO8x Main board
1 Housing
1 ECO8x LED keypad
1 17VAC plug pack
1 12V 7Ah battery (optional)
1 Dialler telephone lead
1 User's manual
1 Installation manual
8 End Of Line resistors 2K2
1 Lead assembly for battery
1 Lead assembly for internal tamper
2 Housing cover screws
4 Circuit board standoffs
ECO8x INSTALLATION MANUAL
Revision 1.5 August 2009
Document Part Number: 890-354
For products:
106-030 ECO8x Control Panel
COPYRIGHT NOTICE
All rights reserved. No part of this publication may be reproduced, transmitted or
stored in a retrieval system in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of Ness.
Ness reserves the right to make changes to features and specifications at any
time without prior notification in the interest of ongoing product development and
improvement.
© 2009 Ness Security Products Pty Ltd ABN 28 069 984 372
