For ZONE TO OUTPUT MAPPING for
armed & 24hr states – see options
P54E – P59E, page 20-21.
Home Mode to RESET output
Home Mode to STROBE output
Home Mode to keypad SONALERT
Home Mode to SIREN output
Day Mode to RESET output
Day Mode to STROBE output
Day Mode to keypad SONALERT
Day Mode to SIREN output
Option No. Description
1E 2E 3E 4E 5E 6E 7E 8E
P63E
HOME MODE & DAY MODE MAPPING
ON ON ON ON
HOME MODE OUTPUT MAPPING
This option selects which outputs are triggered by alarms in Home Mode.
PROGRAMMING SEQUENCE:
P63E 1E–4E toggles the options ON and OFF
1E ON: Home Mode to Reset output
2E ON: Home Mode to Strobe output
3E ON: Home Mode to Keypad Sonalert output
4E ON: Home Mode to Siren output
P63E 1E–4E
PROGRAM MODE LEVEL
Installer, Remote by PC.
FACTORY DEFAULT
1E, 2E ON.
3E, 4E OFF.
RELATED OPTIONS
P64E 1E Brief Home alarm.
P63E 5E–8E
PROGRAM MODE LEVEL
Installer, Remote by PC.
FACTORY DEFAULT
5E, 6E ON.
7E, 8E OFF.
RELATED OPTIONS
P64E 2E Brief Day alarm.
DAY MODE OUTPUT MAPPING
This option selects which outputs are triggered by alarms in Day Mode.
PROGRAMMING SEQUENCE:
P63E 5E-8E toggles the options ON and OFF
5E ON: Day Mode to Reset output
6E ON: Day Mode to Strobe output, (Select this option to activate the STROBE output when a DAY
alarm occurs.
Note that if P64E 2E is ON this option will select Aux 2 Output instead of the Strobe Output. This
allows a remote warning device to be connected (P66E 1E must also be ON).
7E ON: Day Mode to Keypad Sonalert output
8E ON: Day Mode to Siren output
