Ness ECO8x Installation & Programming Manual

“Australia’s largest
designer and
manufacturer of
high quality security
products”
www.ness.com.au
Head Office:
Ness Security Products Pty Ltd
ABN 28 069 984 372
Ph +61 2 8825 9222 Fax +61 2 9674 2520
ness@ness.com.au
NSW
Ph 02 8825 9222 Fax 02 9674 2520
sales@ness.com.au
VIC
Ph 03 9875 6400 Fax 03 9875 6422
nessmelb@ness.com.au
QLD
Ph 07 3399 4910 Fax 07 3217 9711
nessbris@ness.com.au
WA
Ph 08 9328 2511 Fax 08 9227 7073
nessper@ness.com.au
SA
Ph 08 8152 0000 Fax 08 8152 0100
adelaide@ness.com.au

Ness ECO8x Specifications

Power

plug pack voltage	240 V AC
plug pack output voltage	17 V AC
plug pack output current	1.4 A
power supply voltage	13.8 V DC
power supply current	800 mA

Battery

battery voltage	12 V
battery capacity	7.0 Ah
battery charging current	350 mA

Inputs and Outputs

zone inputs	8
end of line resistor	2200 Ohms
maximum keypads	3

Weight and Dimensions

box width	235 mm
box height	300 mm
box depth	90 mm
