Ness ECO8x Installation & Programming Manual

EXAMPLE 5
SIREN WIRING
EXTERNAL INTERNAL
Z8
Z8
C
C
100-238 Top Hat 12V Piezo Screamer
Flush Piezo Screamer
100-172 Ness 12V Internal Siren
100-004
RED
RED
BLACK
BLACK
N.O TAMPER SWITCH
(761-002) Colour: BLACK
N.C TAMPER SWITCH
(SWI920) Colour: WHITE
ALTERNATIVE TAMPER SWITCH WIRING
For N.C. Tamper Switches
STROBE LIGHT
(NOI300)
The terminal block should
be mounted inside the
siren cover.
HORN
SPEAKER
(NOI110)
NESS ECO8x
CONTROL
PANEL
NESS ECO8x
CONTROL
PANEL
NESS ECO8x
NESS ECO8x
CONTROL
PANEL
NESS ECO8x
CONTROL
PANEL
0V
ALARM
TAMPER
N.C.
N.C.
+12V
N.C.
N.C.
NESS QUANTUM DETECTOR
(all models)
REED SWITCH
(N.C. contacts))
PANIC BUTTON
(N.O. contacts))
Zone [1~8]
Zone [1~8]
Zone [1~8]
Zone [1~8]
0V
C
+12V
0V
CC
+12V
0V
CC
+12V
2K2
2K2
NESS QUANTUM DETECTORS
4 WIRE CONNECTION
0V
ALARM
TAMPER
N.C.
N.C.
+12V
N.C.
N.C.
NESS QUANTUM DETECTOR
(all models)
Any zone
programmed
as 24hr
0V
CC
C
+12V
2K2
2K2
EXAMPLE 2
NESS QUANTUM DETECTORS
6 WIRE CONNECTION
With Tamper
EXAMPLE 4
ANY N.C. DEVICE
ANY N.O. DEVICE
NC
NO
COM
EXAMPLE 1 EXAMPLE 3
2K2
2K2
2K2
ECO8x DEVICES WIRING
7
Ness eCO8x CONtrOl PaNel – INstallatION MaNual

Ness ECO8x Specifications

Power

plug pack voltage	240 V AC
plug pack output voltage	17 V AC
plug pack output current	1.4 A
power supply voltage	13.8 V DC
power supply current	800 mA

Battery

battery voltage	12 V
battery capacity	7.0 Ah
battery charging current	350 mA

Inputs and Outputs

zone inputs	8
end of line resistor	2200 Ohms
maximum keypads	3

Weight and Dimensions

box width	235 mm
box height	300 mm
box depth	90 mm
