Table 5. VPN tunnel configuration worksheet
Parameter Value to Be
Entered
Field Selection
Connection Name RoadWarrior N/A
Pre-Shared Key 12345678 N/A
Secure Association N/A Main Mode Manual Keys
Perfect Forward secrecy N/A Enabled Disabled
Encryption Protocol N/A DES 3DES
Authentication Protocol N/A MD5 SHA-1
Diffie-Hellman (DH) Group N/A Group 1 Group 2
Key Life in seconds 28800 (8 hours) N/A
IKE Life Time in seconds 3600 (1 hour) N/A
VPN Endpoint Local IPSecID LAN IP Address Subnet Mask FQDN or Gateway
IP (WAN IP
Address)
Client toGateway N/A N/A Dynamic
Gateway toClient 192.168.3.1 255.255.255.0 22.23.24.25
Virtual Private Networking
104
N600 Wireless Dual Band Gigabit VDSL2 Modem Router DGND3800B
To configure a client-to-gateway VPN tunnel using the VPN Wizard:
1. Select Advanced > VPN Wizard.
