Advanced Settings
95
N600 Wireless Dual Band Gigabit VDSL2 Modem Router DGND3800B
• The Destination IP Address and IP Subnet Mask fields specify that this static route
applies to all 134.177.x.x addresses.
• The Gateway IP Address field specifies that all traffic for these addresses are to be
forwarded to the ISDN router at 192.168.0.100.
• The value in the Metric field represents the number of routers between your network and
the destination. This is a direct connection, so it can be set to the minimum value of 2.
• The Private check box is selected only as a precautionary security measure in case RIP
is activated.
Static Routes
To configure static routes:
1. Select Advanced > Static Routes to display the following screen:
2. Click Add to open the following screen.
3. Fill in the following fields:
• Route Name. Enter a route name for this static route. This name is for identification
purpose only.
• Private. Select this check box if you want to limit access to the LAN only. The static
route is not reported in RIP.
• Active. Select this check box to make this route effective.
• Destination IP Address. Enter the IP address of the final destination.
• IP Subnet Mask. Enter the IP subnet mask for this destination. If the destination is a
single host, type 255.255.255.255.
• Gateway IP Address. Enter the gateway IP address, which has to be a router on the
same LAN segment as the modem router.
• Metric. Enter a number between 2 and 15. This represents the number of routers
between your network and the destination. Usually, a setting of 2 or 3 works.
