Figure 2. Front panel model M4300-12X12F
DescriptionNumber
Power and Fan LEDs1
Stack ID LED2
USB port3
Stack Master LED4
Reset button5
Mini USB console port6
10GBASE-X SFP+ ports7
10GBASE-T ports8
The following figure illustrates the front panel of full-width model M4300-24X24F.
Figure 3. Front panel model M4300-24X24F
DescriptionNumber
Power 1, Power 2, and Fan LEDs1
Stack ID LED2
USB port3
