3
Installation
This chapter describes the installation procedures for the switch. Switch installation involves the steps described
in the following sections:
Step 1: Prepare the site
Step 2: Protect Against Electrostatic Discharge
Step 3: Unpack the Switch
Step 4: Install the Switch
Step 5: Check the Installation
Optional Step 6: Install SFP Transceiver Modules
Step 7: Apply AC Power and Check the LEDs
Optional Step 8: Install a Second Power Supply Unit
Optional Step 9: Connect a Redundant Power Supply
Optional Step 10: Connect a Console to the Switch
Optional Step 11: Replace a Half-width Switch in a Rack
36
Managed Stackable Switch Series M4300
