LEDs, M4300X Series Full 10G Models with RJ45/SFP+ Combo
Ports
The following table describes the LEDs on the front panel of the full 10G models.
Table 3. LEDs full 10G models with RJ45/SFP+ Combo Ports
DesignationLED
Solid green .The power module is present, is supplying power to the switch, and is
functioning normally.
Solid yellow.The switch is booting
Blinking yellow.The system boot-up failed or another failure occurred
Off . Power is not supplied to the switch
Because model M4300-48X can support two PSUs, the front panel
provides both a Power 1 LED and Power 2 LED..
Note
Power
Solid green.The fans are functioning normally.
Blinking yellow. One or more fans failed.
Off. Power is not supplied to the switch.The fans are off.
Fan
Solid green.The switch is functioning as a master in a stack.
Off.The switch is not a member of a stack or is functioning as a slave in a stack.
Stack Master
The Stack LED contains segments that can indicate the stack unit number of the switch.
Solid green indicating a number. The switch is a member of a stack.The LED
displays the stack unit number.
Solid green indicating E.The switch functions in ECO mode with all port LEDs
turned off.
Off.The switch is not a member of a stack.
Stack ID
Hardware Overview
29
Managed Stackable Switch Series M4300
