Table 2. LEDs 1G models with 10G uplinks (Continued)
DescriptionLED
Off. No SFP+ module link is established on the fiber port.
Solid green .The fiber port established a valid 10 Gbps link.
Blinking green .The fiber port is transmitting or receiving packets at 10 Gbps.
Solid yellow.The fiber port established a valid 1 Gbps link.
Blinking yellow.The fiber port is transmitting or receiving packets at 1 Gbps.
10GBASE-X SFP+ ports
(one LED per port)
Left side speed LED:
Solid green. A valid 1000 Mbps link is established on the port.
Solid yellow. A valid 10/100 Mbps link is established on the port
Off. No link is established on the port.
Right side activity/link LED
Solid green. A valid link is established on the port
Blinking green.The port is transmitting or receiving packets.
Off. No link is established on the port.
OOB Ethernet port
Hardware Descriptions, M4300 Series Full 10G Models
with RJ45/SFP+ Combo Ports
This section describes the switch hardware features for the following models:
M4300-24X. Switch model with twenty copper RJ45 ports and four 10G RJ45/SFP+ combo ports in a
half-width chassis
M4300-48X. Switch model with forty-four copper RJ45 ports and four 10G RJ45/SFP+ combo ports in
a full-width chassis
Front Panel, M4300 Series Full 10G Models with RJ45/SFP+
Combo Ports
The models provide twenty or forty-four independent 10GBASE-T autosensing ports and four 10G RJ45/SFP+
combo ports.The following figure illustrates the front panel of model M4300-24X.
Hardware Overview
25
