Table 3. LEDs full 10G models with RJ45/SFP+ Combo Ports (Continued)
DesignationLED
Left side speed LED:
Solid green. A valid 1000 Mbps link is established on the port.
Solid yellow. A valid 10/100 Mbps link is established on the port.
Off. No link is established on the port.
Right side activity/link LED:
Solid green. A valid link is established on the port.
Blinking green. The port is transmitting or receiving packets.
Off. No link is established on the port
OOB Ethernet port
Off. No SFP+ module link is established on the fiber port.
Solid green.The fiber port established a valid 10 Gbps link.
Blinking green.The fiber port is transmitting or receiving packets at 10 Gbps.
Solid yellow.The fiber port established a valid 1 Gbps link.
Blinking yellow.The fiber port is transmitting or receiving packets at 1 Gbps
10GBASE-X SFP+ ports
(one LED per port)
Off. No SFP+ module link is established on the copper port.
Solid green.The copper port established a valid 10 Gbps link.
Blinking green.The copper port is transmitting or receiving packets at 10 Gbps.
Solid yellow.The copper port established a valid 1 Gbps or 100 Mbps link.
Blinking yellow.The copper port is transmitting or receiving packets at 1 Gbps or
100 Mbps
10GBASE-T RJ45 ports
(one LED per port)
Switch Hardware Interfaces
This section describes the hardware interfaces of the M4300 series switch models.
10GBASE-T Ports
To enable high-speed copper and long-distance connections on the switch, RJ-45 10GBASE-T copper ports
support speeds of up to 10 Gbps.
Hardware Overview
30
Managed Stackable Switch Series M4300
