NETGEAR WAC104 User Manual

(Continued)
DescriptionField
From the Channel menu, select an individual channel. The default channel depends on
your selection from the Region menu.
Note: In some regions, not all channels are available. Do not change the channel unless
you experience interference (shown by lost connections or slow data transfers). If this
situation occurs, experiment with different channels to see which is the best.
Note: If you use multiple WiFi access points (APs), reduce interference by selecting different
channels for adjacent APs. We recommend a channel spacing of four channels between
adjacent APs.
Channel
From the Mode menu, select one of the following modes:
•
Up to 173 Mbps. Legacy mode. This mode allows 802.11ac, 802.11n, and 802.11a
devices to join the network but limits 802.11ac and 802.11n devices to functioning at up
to 173 Mbps.
•
Up to 400 Mbps. Neighbor-friendly mode for reduced interference with neighboring
WiFi networks. This mode allows 802.11ac, 802.11n, and 802.11a devices to join the
network but limits 802.11ac devices to functioning at up to 400 Mbps.
•
Up to 867 Mbps. Performance mode. This mode allows 802.11ac, 802.11n, and 802.11a
devices to join the network and allows 802.11ac devices to function at up to 867 Mbps.
This mode is the default mode.
Mode
By default, the AP broadcasts its SSID so that WiFi stations can detect the WiFi name (SSID)
in their scanned network lists. To turn off the SSID broadcast, clear the Enable SSID
Broadcast check box. Turning off the SSID broadcast provides additional WiFi security,
but users must know the SSID to be able to join the WiFi network of the AP.
Note: If you set up a WiFi distribution system (WDS; see Set up a WiFi distribution system
on page 76), you must keep the SSID broadcast enabled.
Enable SSID
Broadcast
User Manual37Manage the Basic WiFi Network
Settings
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
