4. Select Administration > Set Password.
The Set Password page displays.
5.
If you did not yet do so, select the Enable Password Reset check box.
6. Select two security questions and provide answers to them.
7. Click the Apply button.
Your settings are saved.
Recover the local device admin password
During the initial log-in process, you must both customize the local device password
and set up password recovery. If three local login failures occur, you can try to recover
the password. This recovery process is supported in the Internet Explorer, Firefox,
Chrome, and Safari browsers.
To recover your local device password:
1.
Connect your computer or mobile device to the AP in one of the following ways
Connect directly to the AP’s WiFi network or LAN.
Connect to the same network that the AP is connected to.
2.
Launch a web browser and enter www.aplogin.net in the address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use aplogin.net on page 24.
A login window displays.
3. Enter your local device password.
If you enter an incorrect password three times, you are prompted to enter the serial
number of the AP.
The serial number is on the AP label.
4.
Enter the serial number of the AP.
5. Click the Continue button.
A page displays requesting the answers to your security questions.
6. Enter the saved answers to your security questions.
7. Click the Continue button.
A window displays prompts for the answers to your security questions.
User Manual54Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104

Table of Contents

Other manuals for NETGEAR WAC104

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR WAC104 and is the answer not in the manual?

NETGEAR WAC104 Specifications

General IconGeneral
Ethernet WAN-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)867 Mbit/s
Number of WLAN connections (max)128
WLAN data transfer rate (first band)300 Mbit/s
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Antennas quantity3
Security algorithmsWEP, WPA-PSK, WPA2-PSK
Power source typeAC
Power consumption (typical)8.1 W
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, WPS
USB portNo
Ethernet LAN (RJ-45) ports4
Storage temperature (T-T)-120 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
CertificationCE (EN60950)
Mean time between failures (MTBF)285000 h
Cables includedLAN (RJ-45)
Package depth192 mm
Package width247 mm
Package height98 mm
Package weight780 g
Harmonized System (HS) code85176990
Shipping (inner) case width507 mm
Shipping (inner) case height270 mm
Shipping (inner) case length399 mm
Shipping (inner) case net weight8620 g
Number of layers per pallet (sea)7 pc(s)
Number of cartons per pallet layer5 pc(s)
Quantity per shipping (inner) case10 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth181.45 mm
Width239.65 mm
Height40.6 mm
Weight385 g
