NETGEAR WAC104 User Manual

Top panel with LEDs
The status LEDs are located on the top panel of the AP.
Figure 2. Overview of the LEDs
Table 1. LED descriptions
DescriptionLED
Solid green. The AP is ready.
Solid green temporarily, blinking green temporarily, and finally solid green. The
AP is starting or was reset to factory default settings and is restarting. For more
information about resetting the AP to factory default settings, see Return the AP to its
factory default settings on page 55.
Blinking green. The AP is starting or upgrading firmware. If the Power LED is blinking
green at any other time, see Power LED remains blinking green on page 85.
Off. Power is not supplied to the AP.
Power
Solid green. (Wi-Fi Protected Setup) is ready for use. By default, the WPS LED is off.
Blinking green for two minutes. Someone pressed the WPS button on the AP to join
the WiFi network. For more information, see Use Wi-Fi Protected Setup to join the WiFi
network of the AP on page 30.
WPS
Solid green. One or both WiFi radios are operating.
Blinking green. One or both WiFi radios are sending or receiving traffic.
Off. Both WiFi radios are off. For more information, seeControl the WiFi radios on page
43.
WiFi
Ethernet LAN ports 1–4:
Solid green. A powered-on Ethernet device is connected to the LAN port.
Blinking green. The LAN port is sending or receiving traffic.
Off. No powered-on Ethernet device is connected to the LAN port.
LAN
User Manual10Hardware Overview of the
Access Point
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
