NETGEAR WAC104 User Manual

4. Select Administration > Status.
The following table describes the fields and columns of the table on the page.
DescriptionField or Column
The time elapsed since the AP was last restarted.System Up Time
The statistics for the LAN (Ethernet) ports, WLAN b/g/n, and WLAN a/n/ac ports. For
each port, the page displays the information that is described in this table.
Port
The link status of the port.Status
The number of packets transmitted on this port since reset or manual clear.TxPkts
The number of packets received on this port since reset or manual clear.RxPkts
The number of packets that collided on this port since reset or manual clear.Collisions
The detected rate of packet transmission in bytes per second on this port.Tx B/s
The detected rate of packet reception in bytes per second on this port.Rx B/s
The time elapsed since this port acquired the link.Up Time
The interval at which the statistics are updated on this page. For more information,
see Change the traffic statistics polling frequency on page 65.
Poll Interval
Change the traffic statistics polling frequency
You can change the polling frequency or stop traffic polling. For information about the
traffic statistics, see View the traffic statistics on page 64.
User Manual65Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
