(Continued)
DescriptionField
Displays whether the 5 GHz band of the WiFi network broadcasts its SSID.Broadcast SSID
Displays whether the AP keeps its existing WiFi settings when you use WPS to
connect a device to the 5 GHz band of the WiFi network:
•
Configured. The AP keeps its existing WiFi settings. This is the default setting.
•
Not configured. The AP generates a random SSID and passphrase and
changes the security mode to WPA/WPA2-PSK mixed mode.
For more information, see Manage the WPS settings on page 73.
Wi-Fi Protected Setup
Note: If you set up a WiFi distribution system (WDS; see Set up a WiFi distribution
system on page 76), one or more Wireless Repeater panes show. Depending on the
WDS configuration, the MAC address of the base station or the MAC addresses of the
repeaters display.
View the traffic statistics
You can view the traffic statistics for the ports of the AP.
To view the traffic statistics for the ports of the AP:
1.
Connect your computer or mobile device to the AP in one of the following ways:
•
Connect directly to the AP’s WiFi network or LAN.
•
Connect to the same network that the AP is connected to.
2.
Launch a web browser and enter http://www.aplogin.net (or aplogin.net) in the
address field.
Instead, if you are connected to same network as the AP, enter the LAN IP address
that is assigned to the AP. For information about finding the IP address, see Find the
IP address of the AP when you cannot use aplogin.net on page 24.
A login window displays.
3. Enter the AP local device password.
The local device password is the one that you specified. The local device password
is case-sensitive.
The Home page displays.
User Manual64Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104
