NETGEAR WAC104 User Manual

(Continued)
DescriptionField
The IP address that the AP uses. By default, this IP address is 192.168.0.100.
After the AP receives an IP address from your router or a DHCP server in your
network, or if you configure a static IP address, the IP address is different from
the default address.
IP Address
The IP subnet mask that the AP uses.Subnet Mask
The gateway through which the AP connects to the Internet.Default Gateway
The IP address of the Domain Name System (DNS) server that the AP uses.Domain Name Server
Indicates whether the DHCP client of the AP is enabled or disabled. By default,
the DHCP client is enabled.
DHCP Client Status
Wireless Settings (2.4GHz b/g/n)
The settings of the WiFi port for the 2.4 GHz band of the WiFi network. For information about how to configure
these settings, see Manage the basic WiFi settings and WiFi security of the WiFi network on page 33 and
Control the WiFi radios on page 43.
The AP mode is always AP.AP Mode
The channel that the 2.4 GHz band of the WiFi network uses.Channel
The WiFi network name for the 2.4 GHz band of the WiFi network.SSID
The WiFi Mbps settings that the 2.4 GHz band of the WiFi network uses.Mode
Displays whether the 2.4 GHz band of the WiFi network broadcasts its SSID.Broadcast SSID
Displays whether the AP keeps its existing WiFi settings when you use WPS to
connect a device to the 2.4 GHz band of the WiFi network:
•
Configured. The AP keeps its existing WiFi settings. This is the default setting.
•
Not configured. The AP generates a random SSID and passphrase and
changes the security mode to WPA/WPA2-PSK mixed mode.
For more information, see Manage the WPS settings on page 73.
Wi-Fi Protected Setup
Wireless Settings (5GHz a/n/ac)
The settings of the WiFi port for the 5 GHz band of the WiFi network. For information about how to configure
these settings, see Manage the basic WiFi settings and WiFi security of the WiFi network on page 33 and
Control the WiFi radios on page 43.
The AP mode is always AP.AP Mode
The channel that the 5 GHz band of the WiFi network uses.Channel
The WiFi network name for the 5 GHz band of the WiFi network.SSID
The WiFi Mbps settings that the 5 GHz band of the WiFi network uses.Mode
User Manual63Manage the AP and Monitor the
Traffic
802.11ac Wireless Access Point Model WAC104

NETGEAR WAC104 Specifications

General

Ethernet WAN	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	128
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Power source type	AC
Power consumption (typical)	8.1 W
Product type	Tabletop router
Product color	Black
LED indicators	LAN, WPS
USB port	No
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-120 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE (EN60950)
Mean time between failures (MTBF)	285000 h
Cables included	LAN (RJ-45)
Package depth	192 mm
Package width	247 mm
Package height	98 mm
Package weight	780 g
Harmonized System (HS) code	85176990
Shipping (inner) case width	507 mm
Shipping (inner) case height	270 mm
Shipping (inner) case length	399 mm
Shipping (inner) case net weight	8620 g
Number of layers per pallet (sea)	7 pc(s)
Number of cartons per pallet layer	5 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	181.45 mm
Width	239.65 mm
Height	40.6 mm
Weight	385 g
